Fire Assay Fusion Furnace

Key Advantages

Industrial-grade compatibility with multipour/multiload systems boosts efficiency
User-friendly design simplifies maintenance and operation
Precise temperature control ensures consistent heating
Safety features include electronic protection and hands-free pneumatic doors
Energy-efficient and environmentally friendly design
Durable heating elements and easy consumable replacement
Customization is available

Fire Assay Fusion Furnace

The fire assay process is a fundamental and time-honored technique in the mining and metallurgical industries, used to accurately determine the concentration of precious metals such as gold, silver, and platinum group elements (PGEs) in various ore samples and metallurgical products.

DECENT Fire Assay Fusion Furnace is essential for laboratories conducting precious metal analysis. It melts crushed ore samples mixed with fluxes in refractory clay crucibles. The industrial-sized furnaces have spacious chambers that can hold multiple crucibles simultaneously, enhancing laboratory efficiency and reducing manual operations. DECENT fusion furnaces are equipped with an advanced automatic temperature control system that ensures uniform and stable high temperatures, reaching up to 1200°C. This precise thermal management is crucial for the reliability of the fire assay process and the accuracy of analytical results.

Chat Now

Equipment Construction

- Durable frame of 2mm galvanized steel with electrostatic paint resists corrosion.
- Furnace door with alumina and aluminum silicate offers excellent insulation.
- Silicon carbide heating elements provide chamber uniform heat and long life.
- Independent muffle and plate design simplifies consumable replacement.
- Pneumatic door operated by foot pedal for hands-free convenience.
- K-type thermocouple and electronic controller ensure precise heating up to 1200°C.

Technical Parameters

Model	Muffle No.	Working Area (WxDxH)	Crucibles Loading	Controler	Heating Element	Door Opening Method	Air Compressor Recommended Air Pressure	Rated Temperature	Power	Dimension (WxDxH)
Model	Muffle No.	(mm)	(Qty x Size)	Controler	Heating Element	Door Opening Method	(MPa)	(℃)	(kW)	(mm)
DE1220FF	No. 3	370450220	12x50g/65g 15x/40g/55g 20x30g	Transformer 3ph, 20kVA	Silicon Carbide Element	Pneumatic	0.4-0.5	1200	11-18	113710411654
DE2030FF	No. 6	470570220	20x50g/65g 30x30g/40g/55g	Transformer 3ph, 25kVA	Silicon Carbide Element	Pneumatic			17-23	123711331654
DE2536FF	No. 7	590560210	25x50g/65g 36x30g/40g/55g	Transformer 3ph, 30kVA	Silicon Carbide Element	Pneumatic			17-28	136711311686
DE3042FF	No. 9	670650255	30x50g/65g 42x30g/40g/55g	Transformer 3ph, 30kVA	Silicon Carbide Element	Pneumatic			17-28	–
